|Name, Symbol, Number||hydrogen, H, 1|
|Group, Period, Block||1, 1, s|
|Atomic mass||1.00794(7) g/mol|
|Electrons per shell||1|
|Density||(0 °C, 101.325 kPa)
|Melting point||14.01 K
(−259.14 °C, −434.45 °F)
|Boiling point||20.28 K
(−252.87 °C, −423.17 °F)
|Triple point||13.8033 K, 7.042 kPa|
|Critical point||32.97 K, 1.293 MPa|
|Heat of fusion||(H2) 0.117 kJ/mol|
|Heat of vaporization||(H2) 0.904 kJ/mol|
|Heat capacity||(25 °C) (H2)
|Oxidation states||1, −1
|Electronegativity||2.20 (Pauling scale)|
|Ionization energies||1st: 1312.0 kJ/mol|
|Atomic radius||25 pm|
|Atomic radius (calc.)||53 pm (Bohr radius)|
|Covalent radius||37 pm|
|Van der Waals radius||120 pm|
|Thermal conductivity||(300 K) 180.5 mW/(m·K)|
|Speed of sound||(gas, 27 °C) 1310 m/s|
|CAS registry number||1333-74-0 (H2)|
Hydrogen (chemical symbol H, atomic number 1) is the lightest chemical element and the most abundant of all elements, constituting roughly 75 percent of the elemental mass of the universe. Stars in the main sequence are mainly composed of hydrogen in its plasma state.
In the Earth's natural environment, free (uncombined) hydrogen is relatively rare. At standard temperature and pressure, it takes the form of a colorless, odorless, tasteless, highly flammable gas made up of diatomic molecules (H2). On the other hand, the element is widely distributed in combination with other elements, and many of its compounds are vital for living systems. Its most familiar compound is water (H2O).
Elemental hydrogen is industrially produced from hydrocarbons such as methane, after which most elemental hydrogen is used "captively" (meaning locally, at the production site). The largest markets are about equally divided between fossil fuel upgrading (such as hydrocracking) and ammonia production (mostly for the fertilizer market).
The most common naturally occurring isotope of hydrogen, known as protium, has a single proton and no neutrons. In ionic compounds, it can take on either a positive charge (becoming a cation, H+, which is a proton) or a negative charge (becoming an anion, H−, called a hydride). It plays a particularly important role in acid-base chemistry, in which many reactions involve the exchange of protons between soluble molecules. As the only neutral atom for which the Schrödinger equation can be solved analytically, study of the energetics and bonding of the hydrogen atom has played a key role in the development of quantum mechanics.
The term hydrogen (Latin: 'hydrogenium') can be traced to a combination of the ancient Greek words hydor, meaning "water," and genes, meaning "forming." This refers to the observation that when hydrogen burns, it produces water.
Hydrogen is the most abundant element in the universe, making up 75 percent of normal matter by mass and over 90 percent by number of atoms. This element is found in great abundance in stars and gas giant planets. Molecular clouds of H2 are associated with star formation. Hydrogen plays a vital role in powering stars through proton-proton reaction nuclear fusion.
Throughout the universe, hydrogen is mostly found in the atomic and plasma states whose properties are quite different from molecular hydrogen. As a plasma, hydrogen's electron and proton are not bound together, resulting in very high electrical conductivity and high emissivity (producing the light from the sun and other stars). The charged particles are highly influenced by magnetic and electric fields. For example, in the solar wind they interact with Earth's magnetosphere giving rise to Birkeland currents and the aurora. Hydrogen is found in the neutral atomic state in the Interstellar medium. The large amount of neutral hydrogen found in the damped Lyman-alpha systems is thought to dominate the cosmological baryonic density of the universe up to redshift z=4.
Under ordinary conditions on Earth, elemental hydrogen exists as the diatomic gas, H2 (for data see table). However, hydrogen gas is very rare in the Earth's atmosphere (1 part per million by volume) because of its light weight, which enables it to escape Earth's gravity more easily than heavier gases. Although H atoms and H2 molecules are abundant in interstellar space, they are difficult to generate, concentrate and purify on Earth. Still, hydrogen is the third most abundant element on the Earth's surface. Most of the Earth's hydrogen is in the form of chemical compounds such as hydrocarbons and water. Hydrogen gas is produced by some bacteria and algae and is a natural component of flatus. Methane is a hydrogen source of increasing importance.
Hydrogen gas, H2, was first artificially produced and formally described by T. Von Hohenheim (also known as Paracelsus, 1493–1541) via the mixing of metals with strong acids. He was unaware that the flammable gas produced by this chemical reaction was a new chemical element. In 1671, Robert Boyle rediscovered and described the reaction between iron filings and dilute acids, which results in the production of hydrogen gas.
In 1766 Henry Cavendish was the first to recognize hydrogen gas as a discrete substance, by identifying the gas from a metal-acid reaction as "inflammable air" and further finding that the gas produces water when burned. Cavendish had stumbled on hydrogen when experimenting with acids and mercury. Although he wrongly assumed that hydrogen was a liberated component of the mercury rather than the acid, he was still able to accurately describe several key properties of hydrogen. He is usually given credit for its discovery as an element. In 1783, Antoine Lavoisier gave the element the name “hydrogen” when he (with Pierre-Simon Laplace) reproduced Cavendish's finding that water is produced when hydrogen is burned. Lavoisier's name for the gas won out.
One of the first uses of H2 was for balloons, and later airships. The H2 was obtained by reacting sulfuric acid and metallic iron. Infamously, H2 was used in the Hindenburg airship that was destroyed in a midair fire. The highly flammable hydrogen (H2) was later replaced for airships and most balloons by the unreactive helium (He).
Because of its relatively simple atomic structure, consisting only of a proton and an electron, the hydrogen atom, together with the spectrum of light produced from it or absorbed by it, has been central to the development of the theory of atomic structure. Furthermore, the corresponding simplicity of the hydrogen molecule and the corresponding cation H2+ allowed fuller understanding of the nature of the chemical bond, which followed shortly after the quantum mechanical treatment of the hydrogen atom had been developed in the mid-1920s.
One of the first quantum effects to be explicitly noticed (but not understood at the time) was a Maxwell observation involving hydrogen, half a century before full quantum mechanical theory arrived. Maxwell observed that the specific heat capacity of H2 unaccountably departs from that of a diatomic gas below room temperature and begins to increasingly resemble that of a monatomic gas at cryogenic temperatures. According to quantum theory, this behavior arises from the spacing of the (quantized) rotational energy levels, which are particularly wide-spaced in H2 because of its low mass. These widely spaced levels inhibit equal partition of heat energy into rotational motion in hydrogen at low temperatures. Diatomic gases composed of heavier atoms do not have such widely spaced levels and do not exhibit the same effect.
The ground state energy level of the electron in a hydrogen atom is 13.6 eV, which is equivalent to an ultraviolet photon of roughly 92 nanometers.
The energy levels of hydrogen can be calculated fairly accurately using the Bohr model of the atom, which conceptualizes the electron as "orbiting" the proton in analogy to Earth's orbit of the sun. However, the electromagnetic force attracts electrons and protons to one another, while planets and celestial objects are attracted to each other by gravity. Because of the discretization of angular momentum postulated in early quantum mechanics by Bohr, the electron in the Bohr model can only occupy certain allowed distances from the proton, and therefore only certain allowed energies.
A more accurate description of the hydrogen atom comes from a purely quantum mechanical treatment that uses the Schrödinger equation or the equivalent Feynman path integral formulation to calculate the probability density of the electron around the proton. Treating the electron as a matter wave reproduces chemical results such as shape of the hydrogen atom more naturally than the particle-based Bohr model, although the energy and spectral results are the same.
Modeling the system fully using the reduced mass of nucleus and electron (as one would do in the two-body problem in celestial mechanics) yields an even better formula for the hydrogen spectra, and also the correct spectral shifts for the isotopes deuterium and tritium. Very small adjustments in energy levels in the hydrogen atom, which correspond to actual spectral effects, may be determined by using a full quantum mechanical theory which corrects for the effects of special relativity, and by accounting for quantum effects arising from production of virtual particles in the vacuum and as a result of electric fields.
In hydrogen gas, the electronic ground state energy level is split into hyperfine structure levels because of magnetic effects of the quantum mechanical spin of the electron and proton. The energy of the atom when the proton and electron spins are aligned is higher than when they are not aligned. The transition between these two states can occur through emission of a photon through a magnetic dipole transition. Radio telescopes can detect the radiation produced in this process, which is used to map the distribution of hydrogen in the galaxy.
Hydrogen is the only element that has different names for its isotopes in common use today (During the early study of radioactivity, various heavy radioactive isotopes were given names, but such names are no longer used. The symbols D and T (instead of 2H and 3H) are sometimes used for deuterium and tritium, but the corresponding symbol P is already in use for phosphorus and thus is not available for protium. IUPAC states that while this use is common, it is not preferred.
There are two different types of diatomic hydrogen molecules that differ by the relative spin of their nuclei. In the orthohydrogen form, the spins of the two protons are parallel and form a triplet state; in the parahydrogen form the spins are antiparallel and form a singlet. At standard temperature and pressure, hydrogen gas contains about 25 percent of the para form and 75 percent of the ortho form, also known as the "normal form." The equilibrium ratio of orthohydrogen to parahydrogen depends on temperature, but since the ortho form is an excited state and has a higher energy than the para form, it is unstable and cannot be purified. At very low temperatures, the equilibrium state is composed almost exclusively of the para form. The physical properties of pure parahydrogen differ slightly from those of the normal form. The ortho/para distinction also occurs in other hydrogen-containing molecules or functional groups, such as water and methylene.
The uncatalyzed interconversion between para and ortho H2 increases with increasing temperature; thus rapidly condensed H2 contains large quantities of the high-energy ortho form that convert to the para form very slowly. The ortho/para ratio in condensed H2 is an important consideration in the preparation and storage of liquid hydrogen: the conversion from ortho to para is exothermic and produces enough heat to evaporate the hydrogen liquid, leading to loss of the liquefied material. Catalysts for the ortho-para interconversion, such as iron compounds, are used during hydrogen cooling.
A molecular form called protonated molecular hydrogen, or H3+, is found in the interstellar medium (ISM), where it is generated by ionization of molecular hydrogen from cosmic rays. It has also been observed in the upper atmosphere of the planet Jupiter. This molecule is relatively stable in the environment of outer space due to the low temperature and density. H3+ is one of the most abundant ions in the universe, and it plays a notable role in the chemistry of the interstellar medium.
Hydrogen is the lightest element in the periodic table, with an atomic mass of 1.00794 g/mol. For lack of a better place, it is generally shown at the top of group 1 (former group 1A). It is, however, a nonmetal, whereas the other members of group 1 are alkali metals.
The solubility and adsorption characteristics of hydrogen with various metals are very important in metallurgy (as many metals can suffer hydrogen embrittlement) and in developing safe ways to store it for use as a fuel. Hydrogen is highly soluble in many compounds composed of rare earth metals and transition metals and can be dissolved in both crystalline and amorphous metals. Hydrogen solubility in metals is influenced by local distortions or impurities in the metal crystal lattice.
Hydrogen gas is highly flammable and will burn at concentrations as low as four percent H2 in air. The combustion reaction may be written as follows:
The reaction generates a large amount of heat. The enthalpy of combustion is – 286 kJ/mol.
When mixed with oxygen across a wide range of proportions, hydrogen explodes upon ignition. Pure hydrogen-oxygen flames are nearly invisible to the naked eye, as illustrated by the faintness of flame from the main space shuttle engines (as opposed to the easily visible flames from the shuttle boosters). Thus it is difficult to visually detect if a hydrogen leak is burning.
The Hindenburg airship flames seen in the adjacent picture are hydrogen flames colored with material from the covering skin of the zeppelin which contained carbon and pyrophoric aluminum powder, as well as other combustible materials. Regardless of the cause of this fire, this was clearly primarily a hydrogen fire since skin of the airship alone would have taken many hours to burn. Another characteristic of hydrogen fires is that the flames tend to ascend rapidly with the gas in air, as illustrated by the Hindenburg flames, causing less damage than hydrocarbon fires. For example, two-thirds of the Hindenburg passengers survived the hydrogen fire, and many of the deaths that occurred were from falling or from gasoline burns.
H2 reacts directly with other oxidizing elements. A violent and spontaneous reaction can occur at room temperature with chlorine and fluorine, forming the corresponding hydrogen halides: hydrogen chloride and hydrogen fluoride.
With the exception of the above-mentioned reactions, H2 is not very reactive under standard conditions. It does, however, form compounds with most elements. Millions of hydrocarbons are known, but they are not formed by the direct reaction of elementary hydrogen and carbon (although synthesis gas production followed by the Fischer-Tropsch process to make hydrocarbons comes close to being an exception, as this begins with coal and the elemental hydrogen is generated in situ). Hydrogen can form compounds with elements that are more electronegative, such as halogens (e.g., F, Cl, Br, I) and chalcogens (O, S, Se); in these compounds hydrogen takes on a partial positive charge. When bonded to fluorine, oxygen, or nitrogen, hydrogen can participate in a form of strong noncovalent bonding called hydrogen bonding, which is critical to the stability of many biological molecules. Hydrogen also forms compounds with less electronegative elements, such as the metals and metalloids, in which it takes on a partial negative charge. These compounds are often known as hydrides.
Hydrogen forms a vast array of compounds with carbon. Because of their general association with living things, these compounds came to be called organic compounds; the study of their properties is known as organic chemistry and their study in the context of living organisms is known as biochemistry. By some definitions, "organic" compounds are only required to contain carbon, but most of them also contain hydrogen, and the carbon-hydrogen bond is responsible for many of their chemical characteristics.
In inorganic chemistry, hydrides can also serve as bridging ligands that link two metal centers in a coordination complex. This function is particularly common in group 13 elements, especially in boranes (boron hydrides) and aluminum complexes, as well as in clustered carboranes.
Compounds of hydrogen are often called hydrides, a term that is used fairly loosely. To chemists, the term "hydride" usually implies that the H atom has acquired a negative or anionic character, denoted H−. The existence of the hydride anion, suggested by G. N. Lewis in 1916 for group I and II salt-like hydrides, was demonstrated by Moers in 1920 with the electrolysis of molten lithium hydride (LiH), that produced a stoichiometric quantity of hydrogen at the anode. For hydrides other than group I and II metals, the term is quite misleading, considering the low electronegativity of hydrogen. An exception in group II hydrides is BeH2, which is polymeric. In lithium aluminum hydride, the AlH4− anion carries hydridic centers firmly attached to the Al(III). Although hydrides can be formed with almost all main-group elements, the number and combination of possible compounds varies widely; for example, there are over one hundred binary borane hydrides known, but only one binary aluminum hydride. Binary indium hydride has not yet been identified, although larger complexes exist.
Oxidation of H2 formally gives the proton, H+. This species is central to discussion of acids, though the term proton is used loosely to refer to positively charged or cationic hydrogen, denoted H+. A bare proton H+ cannot exist in solution because of its strong tendency to attach itself to atoms or molecules with electrons. To avoid the convenient fiction of the naked "solvated proton" in solution, acidic aqueous solutions are sometimes considered to contain the hydronium ion (H3O+) organized into clusters to form H9O4+. Other oxonium ions are found when water is in solution with other solvents.
H2 is produced in chemistry and biology laboratories, often as a byproduct of other reactions; in industry for the hydrogenation of unsaturated substrates; and in nature as a means of expelling reducing equivalents in biochemical reactions.
In the laboratory, H2 is usually prepared by the reaction of acids on metals such as zinc.
Aluminum produces H2 upon treatment with an acid or a base:
The electrolysis of water is a simple method of producing hydrogen, although the resulting hydrogen necessarily has less energy content than was required to produce it. A low-voltage current is run through the water, and gaseous oxygen forms at the anode while gaseous hydrogen forms at the cathode. Typically the cathode is made from platinum or another inert metal when producing hydrogen for storage. If, however, the gas is to be burnt on site, oxygen is desirable to assist the combustion, and so both electrodes would be made from inert metals (iron, for instance, would oxidize, and thus decrease the amount of oxygen given off). The theoretical maximum efficiency (electricity used vs. energetic value of hydrogen produced) is between 80 and 94 percent.
In 2007 it was discovered that an alloy of aluminum and gallium in pellet form added to water could be used to generate hydrogen. The process creates also creates alumina, but the expensive gallium, which prevents the formation of an oxide skin on the pellets, can be reused. This potentially has important implications for a hydrogen economy, since hydrogen can be produced on-site and does not need to be transported.
Hydrogen can be prepared in several different ways but the economically most important processes involve removal of hydrogen from hydrocarbons. Commercial bulk hydrogen is usually produced by the steam reforming of natural gas. At high temperatures (700–1100 °C; 1,300–2,000 °F), steam (water vapor) reacts with methane to yield carbon monoxide and H2.
This reaction is favored at low pressures but is nonetheless conducted at high pressures (20 atm; 600 inHg) since high pressure H2 is the most marketable product. The product mixture is known as "synthesis gas" because it is often used directly for the production of methanol and related compounds. Hydrocarbons other than methane can be used to produce synthesis gas with varying product ratios. One of the many complications to this highly optimized technology is the formation of coke or carbon:
Consequently, steam reforming typically employs an excess of H2O.
Additional hydrogen from steam reforming can be recovered from the carbon monoxide through the water gas shift reaction, especially with an iron oxide catalyst. This reaction is also a common industrial source of carbon dioxide:
Other important methods for H2 production include partial oxidation of hydrocarbons:
and the coal reaction, which can serve as a prelude to the shift reaction above:
Hydrogen is sometimes produced and consumed in the same industrial process, without being separated. In the Haber process for the production of ammonia (the world's fifth-most produced industrial compound), hydrogen is generated from natural gas.
Hydrogen is also produced in usable quantities as a co-product of the major petrochemical processes of steam cracking and reforming. Electrolysis of brine to yield chlorine also produces hydrogen as a co-product.
H2 is a product of some types of anaerobic metabolism and is produced by several microorganisms, usually via reactions catalyzed by iron- or nickel-containing enzymes called hydrogenases. These enzymes catalyze the reversible redox reaction between H2 and its component two protons and two electrons. Evolution of hydrogen gas occurs in the transfer of reducing equivalents produced during pyruvate fermentation to water.
Water splitting, in which water is decomposed into its component protons, electrons, and oxygen, occurs in the light reactions in all photosynthetic organisms. Some such organisms—including the alga Chlamydomonas reinhardtii and cyanobacteria—have evolved a second step in the dark reactions in which protons and electrons are reduced to form H2 gas by specialized hydrogenases in the chloroplast. Efforts have been undertaken to genetically modify cyanobacterial hydrogenases to efficiently synthesize H2 gas even in the presence of oxygen.
Other rarer but mechanistically interesting routes to H2 production also exist in nature. Nitrogenase produces approximately one equivalent of H2 for each equivalent of N2 reduced to ammonia. Some phosphatases reduce phosphite to H2.
Large quantities of H2 are needed in the petroleum and chemical industries. The largest application of H2 is for the processing ("upgrading") of fossil fuels, and in the production of ammonia. The key consumers of H2 in the petrochemical plant include hydrodealkylation, hydrodesulfurization, and hydrocracking. H2 has several other important uses. H2 is used as a hydrogenating agent, particularly in increasing the level of saturation of unsaturated fats and oils (found in items such as margarine), and in the production of methanol. It is similarly the source of hydrogen in the manufacture of hydrochloric acid. H2 is also used as a reducing agent of metallic ores.
Apart from its use as a reactant, H2 has wide applications in physics and engineering. It is used as a shielding gas in welding methods such as atomic hydrogen welding. H2 is used as the rotor coolant in electrical generators at power stations, because it has the highest thermal conductivity of any gas. Liquid H2 is used in cryogenic research, including superconductivity studies. Since H2 is lighter than air, having a little more than 1/15th of the density of air, it was once widely used as a lifting agent in balloons and airships. However, this use was curtailed after the Hindenburg disaster convinced the public that the gas was too dangerous for this purpose. Hydrogen is still regularly used for the inflation of weather balloons.
Hydrogen's rarer isotopes also each have specific applications. Deuterium (hydrogen-2) is used in nuclear fission applications as a moderator to slow neutrons, and in nuclear fusion reactions. Deuterium compounds have applications in chemistry and biology in studies of reaction isotope effects. Tritium (hydrogen-3), produced in nuclear reactors, is used in the production of hydrogen bombs, as an isotopic label in the biosciences, and as a radiation source in luminous paints.
The triple point temperature of equilibrium hydrogen is a defining fixed point on the International Temperature Scale of 1990 (ITS-90).
Hydrogen is not an energy source, except in the hypothetical context of commercial nuclear fusion power plants using deuterium or tritium, a technology presently far from development. The sun's energy comes from nuclear fusion of hydrogen but this process is difficult to achieve on Earth. Elemental hydrogen from solar, biological, or electrical sources costs more in energy to make than is obtained by burning it. Hydrogen may be obtained from fossil sources (such as methane) for less energy than required to make it, but these sources are unsustainable, and are also themselves direct energy sources (and are rightly regarded as the basic source of the energy in the hydrogen obtained from them).
Molecular hydrogen has been widely discussed in the context of energy, as a possible carrier of energy on an economy-wide scale. A theoretical advantage of using H2 as an energy carrier is the localization and concentration of environmentally unwelcome aspects of hydrogen manufacture from fossil fuel energy sources. For example, CO2 sequestration followed by carbon capture and storage could be conducted at the point of H2 production from methane. Hydrogen used in transportation would burn cleanly, without carbon emissions. However, the infrastructure costs associated with full conversion to a hydrogen economy would be substantial. In addition, the energy density of both liquid hydrogen and hydrogen gas at any practicable pressure is significantly less than that of traditional fuel sources.
