LAPACK: Linear Algebra PACKage

Go to the source code of this file.
Functions/Subroutines
subroutine  zspsv (UPLO, N, NRHS, AP, IPIV, B, LDB, INFO)
ZSPSV computes the solution to system of linear equations A * X = B for OTHER matrices
subroutine zspsv  (  character  UPLO,
integer  N,
integer  NRHS,
complex*16, dimension( * )  AP,
integer, dimension( * )  IPIV,
complex*16, dimension( ldb, * )  B,
integer  LDB,
integer  INFO
)
ZSPSV computes the solution to system of linear equations A * X = B for OTHER matrices
Download ZSPSV + dependencies [TGZ] [ZIP] [TXT]ZSPSV computes the solution to a complex system of linear equations A * X = B, where A is an NbyN symmetric matrix stored in packed format and X and B are NbyNRHS matrices. The diagonal pivoting method is used to factor A as A = U * D * U**T, if UPLO = 'U', or A = L * D * L**T, if UPLO = 'L', where U (or L) is a product of permutation and unit upper (lower) triangular matrices, D is symmetric and block diagonal with 1by1 and 2by2 diagonal blocks. The factored form of A is then used to solve the system of equations A * X = B.
[in]  UPLO  UPLO is CHARACTER*1 = 'U': Upper triangle of A is stored; = 'L': Lower triangle of A is stored.
[in]  N  N is INTEGER The number of linear equations, i.e., the order of the matrix A. N >= 0.
[in]  NRHS  NRHS is INTEGER The number of right hand sides, i.e., the number of columns of the matrix B. NRHS >= 0.
[in,out]  AP  AP is COMPLEX*16 array, dimension (N*(N+1)/2) On entry, the upper or lower triangle of the symmetric matrix A, packed columnwise in a linear array. The jth column of A is stored in the array AP as follows: if UPLO = 'U', AP(i + (j1)*j/2) = A(i,j) for 1<=i<=j; if UPLO = 'L', AP(i + (j1)*(2nj)/2) = A(i,j) for j<=i<=n. See below for further details. On exit, the block diagonal matrix D and the multipliers used to obtain the factor U or L from the factorization A = U*D*U**T or A = L*D*L**T as computed by ZSPTRF, stored as a packed triangular matrix in the same storage format as A.
[out]  IPIV  IPIV is INTEGER array, dimension (N) Details of the interchanges and the block structure of D, as determined by ZSPTRF. If IPIV(k) > 0, then rows and columns k and IPIV(k) were interchanged, and D(k,k) is a 1by1 diagonal block. If UPLO = 'U' and IPIV(k) = IPIV(k1) < 0, then rows and columns k1 and IPIV(k) were interchanged and D(k1:k,k1:k) is a 2by2 diagonal block. If UPLO = 'L' and IPIV(k) = IPIV(k+1) < 0, then rows and columns k+1 and IPIV(k) were interchanged and D(k:k+1,k:k+1) is a 2by2 diagonal block.
[in,out]  B  B is COMPLEX*16 array, dimension (LDB,NRHS) On entry, the NbyNRHS right hand side matrix B. On exit, if INFO = 0, the NbyNRHS solution matrix X.
[in]  LDB  LDB is INTEGER The leading dimension of the array B. LDB >= max(1,N).
[out]  INFO  INFO is INTEGER = 0: successful exit < 0: if INFO = i, the ith argument had an illegal value > 0: if INFO = i, D(i,i) is exactly zero. The factorization has been completed, but the block diagonal matrix D is exactly singular, so the solution could not be computed.
The packed storage scheme is illustrated by the following example when N = 4, UPLO = 'U': Twodimensional storage of the symmetric matrix A: a11 a12 a13 a14 a22 a23 a24 a33 a34 (aij = aji) a44 Packed storage of the upper triangle of A: AP = [ a11, a12, a22, a13, a23, a33, a14, a24, a34, a44 ]
Definition at line 163 of file zspsv.f.
