This article is about the shape and mathematical concept of circle. For other uses of the term, see Circle (disambiguation).

In Euclidean geometry, a circle is the set of all points in a plane at a fixed distance, called the radius, from a given point, the center. The length of the circle is called its circumference, and any continuous portion of the circle is called an arc.

A circle is a simple closed curve that divides the plane into an interior and exterior. The interior of the circle is called a disk.

Contents

Mathematically, a circle can be understood in several other ways as well. For instance, it is a special case of an ellipse in which the two foci coincide (that is, they are the same point). Alternatively, a circle can be thought of as the conic section attained when a right circular cone is intersected with a plane perpendicular to the axis of the cone.

Properties

All circles have similar properties. Some of these are noted below.

  • For any circle, the area enclosed and the square of its radius are in a fixed proportion, equal to the mathematical constant π.
  • For any circle, the circumference and radius are in a fixed proportion, equal to 2π.
  • The circle is the shape with the highest area for a given length of perimeter.
  • The circle is a highly symmetrical shape. Every line through the center forms a line of reflection symmetry. In addition, there is rotational symmetry around the center for every angle. The symmetry group is called the orthogonal group O(2,R), and the group of rotations alone is called the circle group T.
  • The circle centered at the origin with radius 1 is called the unit circle.

Chord properties

Chord, secant, and tangent
Arc, sector, and segment

A line segment that connects one point of a circle to another is called a chord. The diameter is a chord that runs through the center of the circle.

  • The diameter is longest chord of the circle.
  • Chords equidistant from the center of a circle are equal in length. Conversely, chords that are equal in length are equidistant from the center.
  • A line drawn through the center of a circle perpendicular to a chord bisects the chord. Alternatively, one can state that a line drawn through the center of a circle bisecting a chord is perpendicular to the chord. This line is called the perpendicular bisector of the chord. Thus, one could also state that the perpendicular bisector of a chord passes through the center of the circle.
  • If a central angle and an inscribed angle of a circle are subtended by the same chord and on the same side of the chord, then the central angle is twice the inscribed angle.
  • If two angles are inscribed on the same chord and on the same side of the chord, then they are equal.
  • If two angles are inscribed on the same chord and on opposite sides of the chord, then they are supplemental.
  • An inscribed angle subtended by a diameter is a right angle.

Sagitta properties

  • The sagitta is a line segment drawn perpendicular to a chord, between the midpoint of that chord and the circumference of the circle.
  • Given the length of a chord, y, and the length x of the sagitta, the Pythagorean theorem can be used to calculate the radius of the unique circle which will fit around the 2 lines :

r=\frac{y^2}{8x}+\frac{x}{2}

Tangent properties

  • The line drawn perpendicular to the end point of a radius is a tangent to the circle.
  • A line drawn perpendicular to a tangent at the point of contact with a circle passes through the center of the circle.
  • Tangents drawn from a point outside the circle are equal in length.
  • Two tangents can always be drawn from a point outside of the circle.

Theorems

Secant-secant theorem
  • The chord theorem states that if two chords, CD and EF, intersect at G, then CG \times DG = EG \times FG. (Chord theorem)
  • If a tangent from an external point D meets the circle at C and a secant from the external point D meets the circle at G and E respectively, then DC^2 = DG \times DE. (tangent-secant theorem)
  • If two secants, DG and DE, also cut the circle at H and F respectively, then DH \times DG = DF \times DE. (Corollary of the tangent-secant theorem)
  • The angle between a tangent and chord is equal to the subtended angle on the opposite side of the chord. (Tangent chord property)
  • If the angle subtended by the chord at the center is 90 degrees then l = √(2) × r, where l is the length of the chord and r is the radius of the circle.
  • If two secants are inscribed in the circle as shown at right, then the measurement of angle A is equal to one half the difference of the measurements of the enclosed arcs (DE and BC). This is the secant-secant theorem.

Analytic results

Equation of a circle

In an x-y coordinate system, the circle with center (a, b) and radius r is the set of all points (x, y) such that


\left( x - a \right)^2 + \left( y - b \right)^2=r^2.

If the circle is centered at the origin (0, 0), then this formula can be simplified to

x^2 + y^2 = r^2 \!\

and its tangent will be

xx_1+yy_1=r^2 \!\

where x1, y1 are the coordinates of the common point.

When expressed in parametric equations, (xy) can be written using the trigonometric functions sine and cosine as

x = a+r\,\cos t,\,\!
y = b+r\,\sin t\,\!

where t is a parametric variable, understood as the angle the ray to (xy) makes with the x-axis.

In homogeneous coordinates each conic section with equation of a circle is

ax2 + ay2 + 2b1xz + 2b2yz + cz2 = 0.

It can be proven that a conic section is a circle if and only if the point I(1,i,0) and J(1,-i,0) lie on the conic section. These points are called the circular points at infinity.

In polar coordinates the equation of a circle is


r^2 - 2 r r_0 \cos(\theta - \varphi) + r_0^2 = a^2.\,

In the complex plane, a circle with a center at c and radius r has the equation | zc | 2 = r2. Since |z-c|^2 = z\overline{z}-\overline{c}z-c\overline{z}+c\overline{c}, the slightly generalized equation pz\overline{z} + gz + \overline{gz} = q for real p, q and complex g is sometimes called a generalized circle. It is important to note that not all generalized circles are actually circles.

Slope

The slope of a circle at a point (xy) can be expressed with the following formula, assuming the center is at the origin and (xy) is on the circle:


y' = - \frac{x}{y}.

More generally, the slope at a point (xy) on the circle (xa)2 + (yb)2 = r2, (i.e., the circle centered at [ab] with radius r units), is given by


y' = \frac{a-x}{y-b},

provided that y \neq b, of course.

Area enclosed

Area of the circle = π × area of the shaded square


  • The area enclosed by a circle is

A = r^2 \cdot \pi = \frac{d^2\cdot\pi}{4} \approx 0{.}7854 \cdot d^2,

that is, approximately 79 percent of the circumscribed square.

Circumference

  • Length of a circle's circumference is

c = \pi d = 2\pi \cdot r.
  • Alternate formula for circumference:

Given that the ratio circumference c to the Area A is


\frac{c}{A} = \frac{2 \pi r}{\pi r^2}.

The r and the π can be canceled, leaving


\frac{c}{A} = \frac{2}{r}.

Therefore solving for c:


c = \frac{2A}{r}

So the circumference is equal to 2 times the area, divided by the radius. This can be used to calculate the circumference when a value for π cannot be computed.

Diameter

The diameter of a circle is


d = 2r= 2 \cdot \sqrt{\frac{A}{\pi}} \approx 1{.}1284 \cdot \sqrt{A}.

Inscribed angles

Inscribed angle theorem

An inscribed angle ψ is exactly half of the corresponding central angle θ (see Figure). Hence, all inscribed angles that subtend the same arc have the same value (cf. the blue and green angles ψ in the Figure). Angles inscribed on the arc are supplementary. In particular, every inscribed angle that subtends a diameter is a right angle.

An alternative definition of a circle

\frac{d_1}{d_2}=\textrm{constant} Apollonius' definition of a circle

Apollonius of Perga showed that a circle may also be defined as the set of points having a constant ratio of distances to two foci, A and B.

The proof is as follows. A line segment PC bisects the interior angle APB, since the segments are similar:


\frac{AP}{BP} = \frac{AC}{BC}

Analogously, a line segment PD bisects the corresponding exterior angle. Since the interior and exterior angles sum to 180^{\circ}, the angle CPD is exactly 90^{\circ}, i.e., a right angle. The set of points P that form a right angle with a given line segment CD form a circle, of which CD is the diameter.
As a point of clarification, note that C and D are determined by A, B, and the desired ratio (i.e. A and B are not arbitrary points lying on an extension of the diameter of an existing circle).

Calculating the parameters of a circle

Early science, particularly geometry and astronomy/astrology, was connected to the divine for most medieval scholars. The compass in this thirteenth century manuscript is a symbol of God's act of Creation, as many believed that there was something intrinsically "divine" or "perfect" that could be found in circles

Given three non-collinear points lying on the circle


\mathrm{P_1} = \begin{bmatrix} x_1 \\ y_1 \\ z_1 \end{bmatrix},
\mathrm{P_2} = \begin{bmatrix} x_2 \\ y_2 \\ z_2 \end{bmatrix},
\mathrm{P_3} = \begin{bmatrix} x_3 \\ y_3 \\ z_3 \end{bmatrix}

Radius

The radius of the circle is given by


\mathrm{r} = \frac
{\left|P_1-P_2\right| \left|P_2-P_3\right|\left|P_3-P_1\right|}
{2 \left|\left(P_1-P_2\right) \times \left(P_2-P_3\right)\right|}

Center

The center of the circle is given by


\mathrm{P_c} = \alpha \, P_1 + \beta \, P_2 + \gamma \, P_3

where


\alpha = \frac
{\left|P_2-P_3\right|^2 \left(P_1-P_2\right) \cdot \left(P_1-P_3\right)}
{2 \left|\left(P_1-P_2\right) \times \left(P_2-P_3\right)\right|^2}

\beta = \frac
{\left|P_1-P_3\right|^2 \left(P_2-P_1\right) \cdot \left(P_2-P_3\right)}
{2 \left|\left(P_1-P_2\right) \times \left(P_2-P_3\right)\right|^2}

\gamma = \frac
{\left|P_1-P_2\right|^2 \left(P_3-P_1\right) \cdot \left(P_3-P_2\right)}
{2 \left|\left(P_1-P_2\right) \times \left(P_2-P_3\right)\right|^2}

Plane unit normal

A unit normal of the plane containing the circle is given by


\hat{n} = \frac
    {\left( P_2 - P_1 \right) \times \left(P_3-P_1\right)}
    {\left| \left( P_2 - P_1 \right) \times \left(P_3-P_1\right) \right|}

Parametric Equation

Given the radius, r , center, Pc, a point on the circle, P0 and a unit normal of the plane containing the circle, \hat{n}, the parametric equation of the circle starting from the point P0 and proceeding counterclockwise is given by the following equation:


\mathrm{R} \left( s \right) = \mathrm{P_c} +
\cos \left( \frac{\mathrm{s}}{\mathrm{r}} \right) \left( P_0 - P_c \right) +
\sin \left( \frac{\mathrm{s}}{\mathrm{r}} \right)
\left[ \hat{n} \times \left( P_0 - P_c \right) \right]

See also


References

  • Altshiller-Court, Nathan. 2007. College Geometry: An Introduction to the Modern Geometry of the Triangle and the Circle. New York, NY: Dover Publications. ISBN 0486458059.
  • Arnone, Wendy. 2001. Geometry for Dummies. Hoboken, NJ: For Dummies (Wiley). ISBN 0764553240.
  • Pedoe, Dan. 1997. Circles: A Mathematical View. Washington, DC: The Mathematical Association of America. ISBN 0883855186.
